RƠ LE NHIỆT DONG A ELECTRIC

Ký hiệu Rơ le nhiệt Dong A electric

Model		DTH22b			DTH40
Nominal rating		Range of control			Range of control
Nominal rating		Minimum	Midium	Maximum	Minimum	Midium	Maximum
Rated current(A)	0.14	0.1	0.14	0.16
	0.21	0.16	0.21	0.25
	0.33	0.25	0.33	0
	0.52	0.4	0.52	0.63
	0.82	0.63	0.82	1
	1.3	1	1.3	1.6
	2.1	1.6	2.1	2.5
	3.3	2.5	3.3	4
	5	4	5	6	4	5	6
	6.5	5	6.5	8	5	6.5	8
	7.5	6	7.5	9	6	7.5	9
	8.5	7	8.5	10	7	8.5	10
	11	9	11	13	9	11	13
	15	12	15	18	12	55	18
	19	16	19	22	16	19	22
	22				18	22	26
	30				24	30	36
	34				28	34	40
	42				34	42	50
	55
	56
	65
	67
	74
	80
	110
	130
	155
	200
The number of elements	2-terminal element	Standard			Standard
The number of elements	3-terminal element	Sub-standard			Sub-standard
Auxiliary contact		1a1b			1a1b
Way of return		Manual / Compatible to automatic operation			Manual / Compatible to automatic operation
Consuming electricity (main 1)		1.8VA/pole			2.0VA/pole
Solo installation unit		DZ22b			DZ40
Application model	3-terminal element type	DTH22b/3			DTH40/30
	Open phase protection type	DTK22b			DTK40
	Single-phase type	DTZ22b			DTZ40
Combinable electronic contactor		DMC9b,12,12b,18b,22b			DMC32b,40b,48b
Combined electronic switch		DMC9b,12,12b,18b,22b			DMC32b,40b,48b
External dimensions(mm)		43 * 72 * 90.5			54 * 75.5 * 92
Certificates obtained		Korea Register of Shipping			Korea Register of Shipping

Model		DTH85			DTH220
Nominal rating		Range of control			Range of control
Nominal rating		Minimum	Midium	Maximum	Minimum	Midium	Maximum
Rated current(A)	0.14
	0.21
	0.33
	0.52
	0.82
	1.3
	2.1
	3.3
	5
	6.5
	7.5
	8.5	7	8.5	10
	11	9	11	13
	15	12	15	18
	19	16	19	22
	22	18	22	26
	30	24	30	36
	34	28	34	40
	42	34	42	50
	55	45	55	65
	56
	65	54	65	75
	67
	74	63	74	85
	80				65	80	100
	110				85	107	125
	130				100	130	160
	155				120	150	180
	200				160	200	240
The number of elements	2-terminal element	Standard			Standard
The number of elements	3-terminal element	Sub-standard			Sub-standard
Auxiliary contact		1a1b			1a1b
Way of return		Manual / Compatible to automatic operation			Manual / Compatible to automatic operation
Consuming electricity (main 1)		3.5VA/pole			2.3VA/pole
Solo installation unit		–			DTH220/3
Application model	3-terminal element type	DTH85/3			DTK220
	Open phase protection type	DTK85			–
	Single-phase type	–			–
Combinable electronic contactor		DMC50,65,75,85			DMC220
Combined electronic switch		DMC50,65,75,85			DMC220
External dimensions(mm)		70 * 87 * 102.5			154 * 114 * 180
Certificates obtained

Model		HRD150			HRD180
Nominal rating		Range of control			Range of control
Nominal rating		Minimum	Midium	Maximum	Minimum	Midium	Maximum
Rated current(A)	0.14
	0.21
	0.33
	0.52
	0.82
	1.3
	2.1
	3.3
	5
	6.5
	7.5
	8.5
	11
	15
	19
	22
	30
	34
	42	34	42	50
	55
	56	45	56	67
	65
	67	54	67	80
	74
	80	65	80	95	65	80	95
	110	90	110	130	90	110	130
	130	105	130	155	105	130	155
	155				125	155	185
	200
The number of elements	2-terminal element	Standard			Standard
The number of elements	3-terminal element	Sub-standard			Sub-standard
Auxiliary contact		1c			1c
Way of return		Manual			Manual
Consuming electricity (main 1)		2.3VA/pole			2.3VA/pole
Solo installation unit		–			–
Application model	3-terminal element type	HRD150/3			HRD180/3
	Open phase protection type	–			–
	Single-phase type	–			–
Combinable electronic contactor		DMC100,125,150C			DMC150,180
Combined electronic switch		DMC100,125,150C			DMC150,180
External dimensions(mm)		124 * 60 * 97			129 * 84 * 97
Certificates obtained
