CONTACTOR DONG A ELECTRIC

Model				DM9C	DM12C	DM18C	DM22C
Rating KS C 4504	3-phase squirrel cage motor	AC3-class	200-220V	2.2kW 11A	2.7kW 13A	3.7kW 18A	4kW 20A
			380-440V	2.7kW 7A	4kW 9A	5.5kW 13A	7.5kW 20A
			500-550V	2.7kW 6A	5.5kW 9A	5.5kW 13A	7.5kW 17A
		AC4-class	200-220V	1.5kW 8A	2.2kW 11A	3.7kW 18A	3.7kW 18A
		AC4-class	380-440V	2.2kW 6A	4kW 9A	4kW 9A	5.5kW 13A
	Single-phase motor		110V	0.4kW 11A	0.5kW 13A	0.75kW 18A	0.9kW 20A
	Single-phase motor		220V	0.8kW 11A	1kW 13A	1.5kW 18A	1.8kW 20A
	Resistance load (DC1-class)	2-pole serial	110V	6A	10A	13A	15A
		2-pole serial	220V	3A	7A	8A	12A
		3-pole serial	110V	8A	12A	18A	20A
		3-pole serial	220V	8A	12A	18A	20A
Lifespan (net circuit)			Electric	250	250	250	250
Lifespan (net circuit)			Mechanical	2500	2500	2500	2500
Auxiliary contact (standard)				1a1b	1a1b	1a1b	1a1b
Auxiliary contact	Side-on			DAU2Sb	DAU2Sb	DAU2Sb	DAU2Sb
Auxiliary contact	Head-on			DAU2C, DAU4C	DAU2C, DAU4C	DAU2C, DAU4C	DAU2C, DAU4C
Installation type				both of spiral and Din rail
External dimension(mm) (width X length X height)				44 X 80.7 X 86.7			44 X 80.8 X 86.7
Installation size(mm) (width X length)				31~36 X 49~65, 35 X 65
Application model	Contractor		Reversible	DM9C-R	DM12C-R	DMC18C-R	DM22C-R
	Switch		Standard type	DMS9C	DMS12C	DMS18C	DMS22C
			Reversible	DMS90-R	DMS12C-R	DMS18C-R	DMS22C-R
			Top casting type (steel)	DMW9C	DMW12C	DMW18C	DMW22C
Thermal overload relay			Standard type	DTH22b			DTH22b
Thermal overload relay			Single Attached type	DTZ22b			DTZ22b

Model				DM32C	DM40C	DM48C
Rating KS C 4504	3-phase squirrel cage motor	AC3-class	200-220V	5.5kW 26A	7.5kW 35A	11kW 48A
			380-440V	11kW 25A	15kW 32A	15kW 32A
			500-550V	11kW 20A	15kW 26A	15kW 26A
		AC4-class	200-220V	4.5kW 20A	5.5kW 25A	7.5kW 35A
		AC4-class	380-440V	7.5kW 17A	11kW 24A	15kW 32A
	Single-phase motor		110V	1.2kW 26A	1.7kW 35A	–
	Single-phase motor		220V	–	–	–
	Resistance load (DC1-class)	2-pole serial	110V	25A	25A	35A
		2-pole serial	220V	12A	12A	15A
		3-pole serial	110V	25A	35A	50A
		3-pole serial	220V	22A	30A	45A
Lifespan (net circuit)			Electric	200	200	200
Lifespan (net circuit)			Mechanical	1500	1500	1500
Auxiliary contact (standard)				2a2b	2a2b	2a2b
Auxiliary contact	Side-on			DAU2Sb	DAU2Sb	DAU2Sb
Auxiliary contact	Head-on			DDAU2C, DAU4C	DDAU2C, DAU4C	DDAU2C, DAU4C
Installation type				both of spiral and Din rail
External dimension(mm) (width X length X height)				66 X 85.5 X 94.5
Installation size(mm) (width X length)				35 X 60, 35 X 75
Application model	Contractor		Reversible	DW32C-R	DM40C-R	DM48C-R
	Switch		Standard type	DMS32C	DMS40C	DMS48C
			Reversible	DMS32C-R	DMS40C-R	DMS48C-R
			Top casting type (steel)	DMW32C	DMW40C	DMW48C
Thermal overload relay			Standard type	DTH40
Thermal overload relay			Single Attached type	DTZ40b

Model				DM50C	DM65C	DM75C
Rating KS C 4504	3-phase squirrel cage motor	AC3-class	200-220V	11kW 50A	15kW 65A	18.5kW 75A
			380-440V	22kW 48A	30kW 65A	37kW 75A
			500-550V	22kW 38A	37kW 60A	37kW 64A
		AC4-class	200-220V	7.5kW 35A	11kW 50A	13kW 55A
		AC4-class	380-440V	15kW 32A	22kW 47A	25kW 52A
	Single-phase motor		110V	–	–	–
	Single-phase motor		220V	–	–	–
	Resistance load (DC1-class)	2-pole serial	110V	35A	35A	50A
		2-pole serial	220V	15A	15A	20A
		3-pole serial	110V	50A	65A	70A
		3-pole serial	220V	40A	50A	55A
Lifespan (net circuit)			Electric	200	200	200
Lifespan (net circuit)			Mechanical	1000	1000	1000
Auxiliary contact (standard)				2a2b	2a2b	2a2b
Auxiliary contact	Side-on			DAU2Sb	DAU2Sb	DAU2Sb
Auxiliary contact	Head-on			DAU-2C, DAU-4C	DAU-2C, DAU-4C	DAU-2C, DAU-4C
Installation type				both of spiral and Din rail
External dimension(mm) (width X length X height)				79 X 109 X 119.5
Installation size(mm) (width X length)				41~47 X 92~100
Application model	Contractor		Reversible	–	–	–
	Switch		Standard type	–	–	–
			Reversible	–	–	–
			Top casting type (steel)	–	–	–
Thermal overload relay			Standard type	DTH85㈜1
Thermal overload relay			Single Attached type	–

Model				DM85C	DM100C
Rating KS C 4504	3-phase squirrel cage motor	AC3-class	200-220V	19kW 80A	25kW 100A
			380-440V	37kW 80A	50kW 100A
			500-550V	45kW 75A	55kW 80A
		AC4-class	200-220V	15kW 65A	19kW 80A
			380-440V	30kW 62A	37kW 75A
	Single-phase motor		110V	–	–
			220V	–	–
	Resistance load (DC1-class)	2-pole serial	110V	50A	80A
			220V	20A	50A
		3-pole serial	110V	80	100A
			220V	A60A	80A
Lifespan (net circuit)			Electric	200	100
			Mechanical	1000	500
Auxiliary contact (standard)				2a2b	2a2b
Auxiliary contact	Side-on			DAU2Sb	DAU2Sb
	Head-on			DAU-2C, DAU-4C	DAU-2C, DAU-4C
Installation type				both of spiral and Din rail
External dimension(mm) (width X length X height)				94 X 140.5 X 134.4
Installation size(mm) (width X length)				55~60 X 130
Application model	Contractor		Reversible	–	–
	Switch		Standard type	–	–
			Reversible	–	–
			Top casting type (steel)	–	–
Thermal overload relay			Standard type	DTH85㈜1
			Single Attached type	–
